Just recreated this motherboard in Minecraft for Pixel Art purposes.

Anyway, here are the specification of the said motherboard I have recreated in schematic form:

= Chipset: AMD B350 chipser.
= CPU socket: AMD AM4 Socket for AMD Ryzen(TM)/7th Generation A-series/Athlon(TM) Processors
RAM slots: 4x DIMM (max 64), DDR4 3200 MHz (OC)/ 2933 MHz (OC)/ 2666 MHz ECC and non-ECC
= Expansion ports: 1x PCIe 3.0/2.0 x16; 2x PCIe 2.0 x1; 2x PCI
= Storage ports: 6x SATA 6 Gb./s port(s); 2x M.2 Socket
= Ports: 4x USB 3.0 port(s); 2x USB 3.1 port(s); 2x USB 3.0 ports; 6x USB 2.0 port(s)
= Video output: DVI-D, HDMI, VGA
= Form factor: ATX
